Ring Die Feed Pellet Machine

Model: YHKJ250; YHKJ320; YHKJ350; YHKJ420

Capacity: 1-1.5t/h; 2-4t/h; 4-6t/h; 8-10t/h

Power: 22kw; 37kw; 55kw; 110kw

Final Pellets: 2.5-8mm

More+

Inquire Now

What is Ring Die Feed Pellet Machine?

Ring die feed pellet machine specially to make feed pellets for poultry, chicken, pig. The material passing through the modulator enters the granulation chamber and rapidly extruded through the ring die and the press roller to form cylindrical pellets.

Feed pellet machine is mainly used for pressing crushed corn, sorghum, wheat and other crushed grains. This kind of feed pellet machine is widely used in feed farm.

Technical Parameter

Model	Capacity(t/h)	Main Motor Power(kw)	Feeder Motor Power(kw)	Conditioner Power(kw)	Dia. Of Ring Die(mm)	Final Pellet (mm)
YHKJ250	1-1.5	22	0.75	1.5	250	2.5-8
YHKJ320	2-4	37	0.75	2.2	320	2.5-8
YHKJ350	4-6	55	0.75	3	350	2.5-8
YHKJ420	8-10	110	1.5	5.5	420	2.5-8

Application

Ring die feed pellet machine can press various crushed grains into feed pellets. Finished pellets are suitable for pig, chicken, cow, sheep, horse, rabbit, duck.

Crushed Grain

Crushed Wheat

Grain Bran

Allfalfa Grass

Pig

Chicken

Cow

Sheep

Advantages

1. The horizontal ring die feed pellet machine has a wide adaptability to materials and can process a variety of compound feeds with different requirements.

2. When processing materials, the temperature is moderate, can maintain the microelements, good tasty and absorption.

3. The feed pellet machine can work more safer with forced material-entrance and overload protection device

4. Feed pellet machine adopts speed-adjust feeding, can control the feeding capacity correctly to fit for different materials and meet the production requirement of pellets with different diameters.

5. The diameter of the finished pellets can be adjusted between 2mm and diameter 8mm(change the die with different diameter), the length can be adjusted between 5-20mm, suitable for animal different growing period.

6. The feed pellets processed by this feed pellet machine have neat appearance, smooth surface and high density, which is convenient for storage and transportation.

Cases Around the Globe

2-3t/h Feed Pellet Production Line in Qatar

Country: Qatar

Capacity: 2-3t/h

Raw Material: corn, wheat, grains

FAQ

Q: Are you manufacturer or trading company?

A: RotexMaster is leading pellet machinery manufacturer in China, also with marketing department and R&D center.
Q: I am newer to biomass industry, how to design suitable pellet plant?

A: Do not worry about that. We already helped many beginners. We can customize 1-30t/h project according to every customer’s needs. Also we can provide turnkey service.
Q: How to prepare for setting up a wood pellet production line?

A: Factory to set up pellet line, store raw material and pellets
Abundant raw material
Staff needed for operating the pellet line
Transformer to offer enough power for pellet line
Q: How can you guarantee the after-sales service?

A: RotexMaster has professional After-sales service system. Onsite installation, debugging, training, maintenance are available worldwide by 20 years experienced and skillful engineers. Also spare parts can be available timely due to oversea warehouses.
Q: Are there some machines in my area I can observe?

A: RotexMaster has exported to more than 89 countries and regions, if there are machines nearby you, we can contact the customer to arrange a visit for you.
Q: What type of raw materials can be pelletized by RotexMaster pellet machine?

A: Waste wood materials, forest waste, agricultural straw, rice husk, peanut shells, bamboo, sugarcane bagasse, alfalfa, grass, palm fiber, coffee husk, fertilizer etc.
Q: How to confirm the compression ratio of mould for my raw material?

A: Our experienced engineers are familiar with many regular raw material. If your raw material is special, do not worry, we can provide free raw material test. You just need to send your raw material to us, we will find the best way to make pellets with it.
Q: What is the main process for making biomass pellets?

A: Coarse Crushing Section(wood splitter, wood chipper)—Crushing Section—Drying Section—Pelletizing Section—Cooling Section—Packing Section—Controlling Section
Q: What is your work flow if we order Rotexmaster equipment?

A: Inquiry—Customize Plant & Quotation—Communication—Order Confirm & Payment Received—Production—Regular Production Tracing—Quality Inspection for Every Product—Book Vessel & Arrange Delivery—Documents Post/Telex Release—Customs Clearance—Arrange Delivery to Clients` Site—Discharge Goods—Arrange Installation & Commissioning & Training
